Celestial Navigation & Land Navigation – Navigation without a Compass

iStock_000013726152Small-538x354Hiking, and in particular hiking in remote areas, is a great experience if approached with due regard for fitness, safety and skill.

One of the major skill categories, is the ability to navigate with or without compass and map. Ideally, no one should head off the beaten track without map or compass, but what if you find yourself in that situation, or you lose or damage your compass?

Here are a few basic land navigation or celestial navigation ‘skills’ that could one day be of use to you.

Land Navigation & Celestial Navigation: Finding direction by using your Watch…

If you have a watch that is working correctly, you can always quickly determine the points of the compass as long as the position of the sun is visible.

The method used varies depending upon which hemisphere (northern or southern) that you happen to be living in. The following methods are described using an analog watch, (that’s a watch with an hour and a minute hand) but they can be applied just as well if you own aT digital watch – just use your imagination to superimpose the 12 hourly numerals and the relevant position of the ‘hour hand’ on the face of your digital watch.

Northern Hemisphere

Holding your watch horizontally, point the ‘hour hand’ of your watch at the sun.

Note the direction that lies exactly midway between the ‘hour hand’ and the numeral twelve on your watch. This will be South.

Once you have established this, it will be easy to determine the other points of the compass.

Southern Hemisphere

Holding your watch horizontally, point the numeral twelve on your watch at the sun.

Note the direction that lies exactly midway between the twelve and the ‘hour hand’.

This will be North.

These methods will give you a good approximation of compass direction.

If your watch happens to be adjusted for daylight saving at the time, then you can ‘remove’ the daylight saving for greater accuracy.

Another method of determining compass points can be used if you do not have a watch. This method takes longer and also requires enough sunlight to cast a shadow…

To find North without a Watch

  • Before noon, on level terrain, position a stick of about 3ft upright into the ground.
  • Mark the tip of its shadow with a peg or stone.
  • Using the tip of the shadow as a radius, draw an arc around the stick.
  • The shadow will shorten as it approaches noon, pulling back from the arc. It will then lengthen again – where the afternoon shadow once again touches the arc, place another peg or stone.
  • Now draw a straight line between the two pegs/stones – this will be an East/West line, with the first peg being in the westerly direction.
  • You can now draw a North/South line at right angles to the East/West line.
Northern Hemisphere Southern Hemisphere

The following (less accurate) method can also be used at any time of the day without drawing an arc…

Peg the tip of the first shadow, then about 30min later peg the tip of the moved shadow. Draw a straight line between the two pegs, and this will be an approximately East/West line, with the first peg again being the westerly one.

(The longer the period left between pegging the tips of the shadow, the more accurate the reading.)

A typical error when lost is a tendency to wander off what you may think is a straight line bearing, sometimes even slowly circling back on yourself.

To prevent this, note an object (tree, rock, terrain feature) that lies directly ahead of you in the direction you wish to travel, then aim for it. When you reach it, take another bearing on the direction you wish to head, sight another object directly ahead of you and repeat the process.

In areas of restricted distance visibility, you may have to repeat this quite often over short ‘legs’ to ensure that you are remaining on course.

Land Navigation & Celestial Navigation: Keeping a course by the Clouds…

What if it’s a cloudy day with no sun visible to get a bearing on, or the bush canopy prevents you getting a clear “shot” at the sun?

Well, if you’re lucky, it may be windy with the clouds moving in a constant direction – note the directional flow of the clouds, and adjust your course relevant to their direction.

e.g., If the clouds are moving from your front from right to left over your shoulders, keep them there, at the same time, sight an object straight ahead of you and head for it.

To retrace your steps in the same general direction, just do an about turn, then keep the clouds moving from behind and now left to right over your shoulders, and repeat the process.

Being aware of your surroundings will often pay off, so try to cultivate that habit.

Land Navigation & Celestial Navigation: Telling the time without a Watch…

Determine North, South, East and West using a compass or the method previously described.

Position your stick at the intersection point of your East/West, North/South lines.

The Eastern point of the arc around the stick will be 1800hrs, the Western point will be 0600hrs, whilst the Northern or Southern (depending on which hemisphere you’re in) midpoint of the arc will be 1200hrs.

The approximate time of day can then be read off the arc using the moving shadow.

Northern Hemisphere Southern Hemisphere
Good luck with these land navigation &  celestial navigation tools!
